The sets are supplied with the following components:
Cylinder Heads (x4)
Domed Pistons (x4)
Rings (x12)
Pin (x4)
Circle Clips (x8)
Dimensions of the various parts:
Cylinder Head Bore Diameter: Ø 77.8mm
Cylinder...
In stock
Alpine A110 1600GS engine - 1596cm³ engine (Type 807G - Bore Ø77.8mm)
Our spare parts for the engine of your Renault Alpine A110
Discover here our wide selection of spare parts available to restore or maintain your Renault Alpine A110 :
- Alpine A110 1600GS Engine - 1596cm³ Engine (Type 807G - Bore Ø77.8mm)
Whether you are looking for: engine piston, liners, segments, crankshaft bearings, connecting rod bearings, side shims, engine gasket set, base gasket, rocker cover, cylinder head gasket, pinion, distribution, timing chain, intake valve, exhaust valve, manifold gasket, crankcase, chain tensioner...At AVP Arnaud Ventoux Pièces, we have everything you need to restore your Alpine A110 Berlinette collection with components from quality.
In stock
Installation into the R18 Turbo engine block requires no modifications or machining
The use of GS 700 cast iron liners is not necessary; these liners are thicker.
In stock
Sheets (x4)
Sheet Dimensions:
Sheet Bore Diameter: Ø 77.8mm
Sheet Flange or Top Diameter (D): Ø 96mm
Sheet Base Diameter (A): Ø 82.50mm
Sheet Height (including skirts, overall) (C): 143.50mm
Sheet Height to Base...
In stock
Segment Characteristics:
Segment Diameter: Ø 77.8mm
Thickness of Upper Segments (Fire-resistant): 1.75mm
Thickness of Intermediate Segments (Waterproof): 2mm
Low ring thickness (Scraper): 4mm
It is essential to...
In stock
The sets are supplied with the following components:
Cylinder Heads (x4)
Domed Pistons (x4)
Rings (x12)
Pin (x4)
Circle Clips (x8)
Dimensions of the various parts:
Cylinder Head Bore Diameter: Ø 77.75mm
Cylinder...
In stock
For piston kit liners Ø 79mm (AVP6085) and Ø 77.8mm (AVP60134)
In stock
Bearing Dimensions:
Dimension: Original (Standard) Dimension
Crankpin Diameter (A): Ø 48.00mm
Housing Diameter (B): Ø 51.60mm
Bearing Width (C): 21.75mm
Bearing Thickness (D): 1.77mm
Smooth, lug-type bearings with no...
In stock
Bearing Dimensions:
Dimension: Repair Dimension (+0.25)
Crankpin Diameter (A): Ø 47.75mm
Housing Diameter (B): Ø 51.60mm
Bearing Width (C): 21.75mm
Bearing Thickness (D): 1.89mm
Smooth, lug-type bearings with no...
In stock
Bearing Dimensions:
Dimension: Repair Dimension (+0.50)
Crankpin Diameter (A): Ø 47.50mm
Housing Diameter (B): Ø 51.60mm
Bearing Width (C): 21.75mm
Bearing Thickness (D): 2.02mm
Smooth, lug-type bearings with no...
In stock
Bearing Dimensions:
Dimension: Stock Dimension (Standard)
Journal Diameter (A): Ø 54.80mm
Housing Diameter (B): Ø 58.75mm
Bearing Width (C): 20.50mm
Bearing Thickness (D): 1.95mm
Smooth, lug-type bearings with grease...
In stock
Bearing Dimensions:
Dimension: Repair Dimension (+0.25)
Junnel Diameter (A): Ø 54.55mm
Housing Diameter (B): Ø 58.75mm
Bearing Width (C): 20.50mm
Bearing Thickness (D): 2.07mm
Smooth, lug-type bearings with grease...
In stock
Bearing Dimensions:
Dimension: Repair dimension (+0.50)
Junnel Diameter (A): Ø 54.30mm
Housing Diameter (B): Ø 58.75mm
Bearing Width (C): 20.50mm
Bearing Thickness (D): 2.20mm
Smooth, lug-type bearings with grease...
In stock
In stock
Out of stock
In stock
Out of stock
Out of stock
Out of stock
In stock
In stock
In stock
In stock
In stock
Suitable for valves with a groove in the upper position (type KK) and for stem diameter 8mm
In stock
Dimensions of the Large Spring:
Outer Diameter: Ø 35.90mm
Inner Diameter: Ø 27.80mm
Wire Diameter: Ø 4.1mm
Free Height (overall): 49.50mm
Dimensions of the Small Spring:
Outer Diameter: Ø 25.90mm
Inner Diameter: Ø...
Out of stock
Thickness : 1mm
Compatible with 1565cm³ to 1647cm³ engines (Type 807 844 and 843):
A110 1600S/SC/SX
A310 1600cc
R12G / R17G
R16.TS/TX
In stock
Length under head: 37mm
Significantly higher strength than the original, ideal for tuned engines
In stock
In stock
In stock
In stock
Out of stock
In stock
In stock
In stock
In stock
Paper gasket thickness: 1.6 mm
Suitable for all 1565cc / 1596cc / 1605cc and 1647cc engines
In stock
In stock
Out of stock
Suitable for:
R8.G (1255cc and 1296cc Engine)
GT4 / Matradjet (1255cc Engine)
A110 1100G and 1300G
A110.1600 S / SC / SI
A310.4 1600VF (Injection) / R12.G / R17.G
Super 5GT Turbo
In stock
Chain 72 links
Adjustable 36 tooth sprocket and 18 tooth sprocket
Out of stock
In stock
In stock
Tendeur à armement automatique par ressort
Présence d'un orifice de graissage pour assurer la lubrification et le maintien en tension du patin contre la chaîne
In stock
Out of stock
Compatible with 1565cm³ to 1647cm³ engines (Type 807 , 844 and 843):
A110 1600S/SC/SX
A310 1600cc
R12G / R17G
R16.TS/TX
In stock
Compatible with 1565cm³ to 1647cm³ engines (type 807, 844, 843):
A110 1800cm³
A310 1600cm³
R12G / R17G
R16.TS / TX
In stock
In stock
In stock
In stock
In stock
In stock
In stock
In stock
Out of stock
Sold with water pump seal, plate seal and plate.
In stock
Sold with water pump seal, plate seal and plate.
In stock
In stock
In stock
