Double distribution chain - 72 links (Superior quality)

Synchro Characteristics:

• • Outer cone with angle (A):6°40'
  • The outer friction faces or sectors (x15) are different: x3 small and x2 large
  • Synchro with a lug on the face opposite the main lugs of the synchro (See diagram)
  • Renault OE Ref: 7700557051

Suitable for 2nd gear synchros for the following gearboxes:

• • • 330 Gearbox: 330- ...
    • Box 336: 336- ...
    • Box 352: 352-30 / 352-31 / 352-33 / ...
    • Box 353: 353- ...
    • Box 364: 364- ...
    • Box 365: 365-05 / 365-10 / 365-14 / 365-20 / 365-24 / 365-33 / ...
    • Box 385: 385-10 ...
    • Box 395: 395-02 / 395-03 ...

We recommend carefully disassembling and identifying the synchros (9° or 6°40' angle, friction sector, etc.) in each gearbox, as we have observed some mix-ups.

The gearbox numbers on the identification plate are not the most reliable indicators for identification.

• Sheet Dimensions: Length 50cm x Width 33cm
• Sheet Thickness: 2.5mm
• Ideal for making oil pan gaskets, timing case gaskets, and cylinder head cover gaskets. These gaskets must be installed with a light clamping force. Temperature limit: 110°C.
• Material made of calibrated cork granules, bonded with nitrile rubber

• OE Renault Ref: 7703090187 / 0857568100 / 7703090277
