Manifold 4 in 1 - R5 Alpine (1223)

• To replace the 3/4"-16UNF oil filter with a M20x150 filter
• Thread on engine block side: 3/4"-16UNF
• Thread on filter side: M20x150
• Overall length: 50mm

• Carburetor mounting distance to the intake manifold: 110mm and 70mm
• Intake manifold height: 76mm
• Manifold supplied with O-rings (x4) and carburetor mounting studs (x8)

The carburetor mounts directly onto the manifold. Four O-rings ensure a tight seal; there's no need to use flexible or rigid flanges.

For Weber 32 DIR: 62/9700 - 58T/8500 - 89/100

Compatible for any Ducellier igniter with an inside diameter of the body of 58.8mm

• Capacitor capacity 0.27µF

Replaces Ducellier 582012

• Stem Length: 38mm
• Diaphragm hole spacing: 27mm
