Trumpet dice seal (cork and rubber)

• Cone diameter: Top of cone Ø11mm / Bottom of cone Ø 12mm
• Cone axis: M10x125
• Ball joint / tie rod axis: M14x150 (Right hand thread)

• Need x2 lengths of 3 meters for a car (Sold individually)

Segment Characteristics:

• • Segment Diameter:Ø 58mm
  • Thickness of Upper Segments (Fire-resistant): 2mm
  • Thickness of Intermediate Segments (1) (Waterproof): 2mm
  • Thickness of intermediate rings2 (Sealing): 2mm
  • Thickness of lower rings (Scraper): 3.5mm

It is essential to check the ring end gap of each ring before installing them on the pistons, according to the valuesgiven by the manufacturer or data in the supplied instructions.

During assembly, the piston ring gaps must be evenly distributed around the piston circumference at 120° intervals.

The central unit is connected as follows:

• The 12V power supply (+ battery) wire on the "X" or "+" terminal
• The Switch or stalk control wire on the "L" or "Z" terminal
• The repeater indicator light wire (LED) on the "P" terminal
