Suitable for:
Sets are supplied with the following:
Dimensions of the different parts:
Piston mounting direction: An arrow drawn perpendicular to the piston axis is marked on the top of the piston. It must be oriented in the direction of engine rotation during the connecting rod's downward stroke (see manufacturer's instructions or diagram).
It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values given by the manufacturer or in the supplied instructions.
During installation, the ring end gap must be evenly distributed around the piston circumference at 120° intervals.
Segment Characteristics:
It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values given by the manufacturer or in the supplied instructions.
During installation, the ring end gap must be evenly distributed around the piston circumference at 120°.
Thicknesses:
White Gasket: 0.06mm
Black Gasket: 0.07mm
Red Gasket: 0.09mm
Suitable for:
Thicknesses:
White Gasket: 0.06mm
Black Gasket: 0.07mm
Red Gasket: 0.09mm
Bearing Dimensions:
