Platinum screw Ducellier Junior (Type 71130)

• Intake pipe : Ø 29mm
• Exhaust pipe : Ø 25mm
• Fixing : holes aligned

• Oil filter thread: M5/8"-18 UNF - 2B
• Overall height: 97.71 mm
• Overall diameter: 95 mm
• Renault OE part number: 8548620 / 0854862000 / 8548078 / 0854807800

Segment Characteristics:

• • Segment Diameter: Ø 54.50 mm
  • Thickness of Upper Segments (Fire-resistant): 2 mm
  • Thickness of Intermediate Segments (Waterproof):2mm
  • Low ring thickness (Scraper): 3.5mm

It is essential to check the ring end gap of each ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the supplied instructions.or the values ​​provided in the instruction manual.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120°.

Kit consisting of two pairs of brake shoes for two front or rear wheels

• Kit sold with brake shoes and linings already glued in place.
• Shoe diameter: Ø 180mm
• Liner width: 32mm

Suitable for:

• 4CV: From 1951 to 1961 (Front and rear brakes)
• Alpine A106: Front and rear brakes
• R4 (R1120 / R1121 / R1122 / R1124): From 1962 to July 1966 (Front brakes)
• R4 Van (R2102 / R2104): From 1962 to July 1966 (Brakes) before)
