Paint for engine block - Aluminum gray - RAL 9006

Synchro Characteristics:

• • Outer cone with angle (A):6°40'
  • The outer friction faces or sectors (x15) are different: x3 small and x2 large
  • Synchro is smooth on the face opposite the synchro lug (See diagram)
  • Renault OE Ref: 7700557052 / 77006713883 / 7700725747

Suitable for 2nd gear synchros for the following gearboxes:

• • • Box 330: 330- ...
    • Box 336: 336- ...
    • Box 352: 352-30 / 352-31 / 352-33 ...
    • Box 353: 353- ...
    • Box 364: 364- ...
    • Box 365: 365-05 / 365-10 / 365-14 / 365-20 / 365-24 / 365-33 ...
    • Box 385: 385-10 ...
    • Gearbox 395: 395-02 / 395-03 ...

We recommend carefully disassembling and identifying the synchros (9° or 6°40' angle, friction sector, etc.) in each gearbox, as we have observed some mix-ups.

The gearbox numbers on the identification plate are not the most reliable indicators for identification.

Dimensions of the Large Spring:

• Outer Diameter: Ø 32.6mm
• Inner Diameter: Ø 25.1mm
• Wire Diameter: Ø 3.70mm
• Free Height (overall): 40.60mm

Dimensions of the Small Spring:

• Outer Diameter: Ø 22.9mm
• Inner Diameter: Ø 17.6mm
• Wire Diameter: Ø 2.60mm
• Overall Height: 39.3mm

Dimensions provided for information purposes only, may vary slightly.

Suitable for:

• R8 : Rear Big Brake Installation
• R5 Alpine Turbo (122B) : Rear Brake
• R12G / R17G : Rear Brake
• R18 / R21 / R25 / R30 : Rear Brake
• A110 : Rear Big Brake Installation
• A310.4 : Rear Brake
• A310 V6 (Pre-1980) : Rear Brake

Brake pads with a retaining stop (B in the diagram) must be installed with this stop facing forward (in the direction of wheel rotation)
