Intake and exhaust manifold for 32 PBIC carburettor

• This ignition harness consists of4 spark plug wires and 1 coil wire.
• We would like to point out that our spark plug wires are made with Ø 7 mm silicone wires, black in color, with a standard copper core (wire material), which indicates that they do not have interference protection.
• If the vehicle is equipped with sensitive electronic accessories, such as Radios, tripmasters, monitors, or certain electronic ignition kits may cause interference or disruption.

• Overall length: 283.5 cm
• Sheath length: 231 cm
• Cable length: 272.5 cm

Suitable for:

• Alpine A108 and GT4
• Dauphine
• Floride

Our cables are made in France and meet the assembly and quality standards of original equipment (OEM) cables from automotive manufacturers.

Thickness 1.9mm

• Special Premium Quality graphite for clutch release bearings
• Important: The release bearing clamping screw must be placed on the side opposite the fork
• It is possible to keep the release bearing and replace only the graphite ring if worn.
• Depending on the diameter of the return spring, it may be necessary to re-drill the release bearing mounting.
• It is recommended to soak the release bearing in warm engine oil and then wipe it dry before installation to avoid squeaking noises

Suitable for vehicles:

• 4CV / Juvaquatre: Type 662 Engine (From June 1956)
• Dauphine / Dauphinoise / Estafette / Floride A106 / A108: Type 670 Engine
• R4: Billancourt Type 800-02/05 Engine (From 1962)

Bearing Dimensions:

• Dimensions: Original (Standard) Dimensions
• Crankpin Diameter (A): Ø 38.00mm
• Housing Diameter (B): Ø 41.14mm
• Bearing Width (C): 21.18mm
• Bearing Thickness (D): 1.57mm
• Smooth, lug-type bearings with no grease holes or grooves
• Bearing Material: Bimetal

The sets are supplied with the following components:

• Liners (x4)
• Domed Pistons (x4)
• Rings (x12)
• Pin (x4)
• Circle clips (x8)

Dimensions of the different parts:

• • Liner bore diameter: Ø 77mm
  • Liner flange or top diameter (D): Ø 96mm
  • Liner base diameter (A): Ø 82.50mm
  • Overall height including skirts of the cylinder liners (C):143.50mm
  • Height from the top of the liner to the base seal area (E): 92.50mm
  • Shaft dimensions: Ø 21x65mm (Cirlip-free mounting)
  • Ring thickness:1.75mm / 2mm / 4mm (Fireproof/Sealing/Scraper)
  • Base seal type: Paper gasket

Piston mounting direction: an arrow drawn perpendicular to The piston pin is located on the top of the piston. It must be oriented in the direction of engine rotation during the connecting rod's downward stroke (see manufacturer's instructions or diagram).

It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the supplied instructions.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120° intervals.
