Guiot fuel pump kit - Diaphragm 6 holes Ø70mm - 4CV / Dauphine / Floride / A106 / A108

This bushing is versatile and can be used in various applications:

• Front stabilizer bar link bushing
• Rear spring travel limiter rod bushing (early model)
• Bushing for the connecting link between the rear lever-arm shock absorber and the axle trumpet (oil-bath lever-arm shock absorber – early model, pre-1950)
• Inner diameter: Ø 9mm
• Outer diameter: Ø 21mm
• Width (including shoulder): 17mm / 21mm
• Renault OE Ref.: 8511922

• This ignition harness consists of4 spark plug wires and 1 coil wire.
• We would like to point out that our spark plug wires are made with Ø 7 mm silicone wires, black in color, with a standard copper core (wire material), which indicates that they do not have interference protection.
• If the vehicle is equipped with sensitive electronic accessories, such as Radios, tripmasters, monitors, or certain electronic ignition kits may cause interference or disruption.

The sets are supplied with the following components:

• Cylinder Heads (x4)
• Domed Pistons (x4)
• Rings (x12)
• Pin (x4)
• Circle Clips (x8)

Dimensions of the various parts:

• • Cylinder Head Bore Diameter: Ø 59.95mm
  • Cylinder Head Flange or Top Diameter (D): Ø 72.75mm
  • Cylinder Head Base Diameter (A): Ø 62.40mm
  • Overall height including skirts of the cylinder liners (C):121mm
  • Height from the top of the liner to the base seal area (E): 112mm
  • Shaft dimensions: Ø 14x49.80mm (Cirlip-free mounting)
  • Ring thickness:1.45mm / 1.45mm / 3mm (Fireproof/Sealing/Scraper)
  • Base seal type: Copper gasket

Piston mounting direction: an arrow drawn perpendicular to the axis of the The piston ring is located on the top of the piston. It must be oriented in the direction of engine rotation during the connecting rod's downward stroke (see manufacturer's instructions or diagram).

It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values ​​specified by the manufacturer or given in the supplied instructions.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120° intervals.

Dimensions:

- Length 145mm

- Interior Ø 46mm and Ø of the rod 10mm

• It is recommended to perform a dry fit of all body components to ensure proper alignment. Adjustments may be necessary.

Shipping available. Contact us to obtain a transport quote and find out our conditions.
