External return spring kit for WEBER DCOE 40 and DCOE 45 carburetor

• Sheet Dimensions: Length 58cm x Width 35cm
• Sheet Thickness: 0.8mm
• Ideal for making carburetor gaskets, fuel pump gaskets, engine and gearbox gaskets (Parts subject to low temperature or pressure). Suitable for all other types of flat gaskets, except those in contact with vapors, up to a temperature limit of 120°C.
• Material made of fiber paper

• Useful length (L on photo diagram number 3): 17mm
• Sold with the pin
• OE Renault / Alpine Ref: 0705837200

• Air intake trumpet/trumpet filters for WEBER 40DCOE carburetor
• Mesh filters made of two layers of stainless steel mesh, with an intermediate filter layer ensuring optimal engine protection
• Easily washable and removable
• Suitable for trumpets with an outer flange diameter between Ø 55mm and 60mm
• Filter inner diameter : Ø 52mm
• Filter outer diameter: Ø 74mm
• The filter length when installed on a 55mm trumpet is 70mm (overall)
• Can be mounted on all the cones in the AVP catalog

Suitable for:

• A110.1600 SC / SI (VD) / SX (VH) / A310.4 : Upper and lower rear wishbone
• R12.G : Lower front wishbone, central rear wishbone

• Slanted hose outlet: Ø 3/8" - 24UNF (Ø 9.52mm)

• Gasket dimensions: Ø 20x12x1mm
• Suitable for WEBER 40DCOE and 45DCOE carburetors
• Number 2 and number 69 on exploded view
• Sold individually, 1 piece required for one carburetor
• Compatible with other WEBER carburetors, see below

• Useful length (L on photo diagram number 3): 19.5mm
• Sold with the pin
• OE Renault / Alpine Ref: 0705322000
