Complete case for manufacturing copper tube fitting cones

• • Angled hose outlet: Ø 3/8" - 24UNF (Ø 9.52mm)

Suitable for:

• • 4CV: Left Rear Brake (From early 1956 to the end of production)
  • Dauphine / Floride: Left Rear Brake
  • Alpine A106 / A108: Left Rear Brake

Kit specifications (Tie rods / Ball joints and boots):

• Ball joint taper diameter (Steering knuckle side): Top of taper Ø 11mm / Bottom of taper Ø 12mm
• Ball joint taper stud thread diameter: M10 x 1.25 (right-hand thread)
• Ball joint stud thread diameter (into tie rod): M14 x 1.50 (right-hand thread)
• Tie rod thread diameter (into steering rack): M12 x 1.00 (right-hand thread)
• Minimum length of tie rod/ball joint assembly: 26 cm (measured from the contact point against the steering rack to the center of the ball joint stud on the steering knuckle side)
• Maximum adjustment of the tie rod/ball joint assembly: 29 cm (measured from the contact point against the steering rack to the center of the ball joint at the steering knuckle end)
• Includes: 2 steering rack boots, 2 steering ball joints (with nuts and locknuts), and 2 steering tie rods.

Suitable for:

• R8 (All models)
• Caravelle / Floride S
• A110 (All models) / Alpine GT4
• Matradjet

This adjustable steering kit replaces the original "fork-type" steering tie rods.

To install the adjustable tie rods, you must remove the steering rack eyelet bushing and replace the steering rack boots with the specific AVP4620 boots (included in the kit).

For diaphragm clutch mechanism

Suitable for:

• Simca 1000 (All models) / R1 / 1200S
• R15 (TS) / R16 (Types L / TL / TS / TX) / R17 TL / TS) : 1600cm³ engine

Suitable for engines:

• Engine Type 662: 4CV / Juvaquatre / A106
• Engine Ventoux Type 670-1: Dauphine (Except R1093 and Gordini R1095) / Estafette / Floride (R1092) / A108

Valve sold individually

To be fitted with reference 6809
