Carburettor Diaphragm - 34 TBIA

Suitable for:

• R8 / A110: Front Brake (Big Brake Assembly)
• R5 Alpine Atmo (1223) and Alpine Turbo (122B): Front Brake
• R12 (All models) / R15TL: Front Brake
• R16(L / TL / TS ) / R16TX (2nd assembly): Front Brake
• A310.4 (n°910 at the end of the series): Front Brake
• A310 V6 (Before 1980): Front Brake

Bearing Dimensions (Sold in packs of 12):

• Crankshaft Diameter: Ø 52.30mm
• Bearing Diameter: Ø 56.0mm
• Width: 17.65mm
• Thickness: 1.84mm

Suitable for the following engines:

• Alpine A310 V6: PRV 112.730 Engine
• Alpine V6 GT (D500): Z6W Engine
• Renault 25 Injection (B29A) : Z7W-702 Engine

OE Renault / Alpine Ref: 7901060645 / 7701460463 / 7701348429

Lift Features:

• Double-acting gas lift
• Mounting center distance: 595mm
• Lift stroke: 250mm
• Mounting eye diameter: Ø 8mm (x2)

Lifts must be mounted with the rod at the bottom, with the case or hood closed.

In most cases, it is not possible to compress the lift by hand due to its force.

• This ignition harness consists of 6 spark plug wires and 1 coil wire.
• We would like to point out that our spark plug harnesses are made with 7mm diameter, black silicone wires with a standard copper core, which means they do not have interference protection.
• If the vehicle is equipped with sensitive electronic accessories, such as radios, tripmasters, monitors, or certain electronic ignition kits, some interference or disruption may be observed.

- Primary winding resistance: 3.1 ohms

- Coil compatible with electronic ignition kits ref 4798 and ref 4799
