Rubber (diabolo) mounting bracket between spacer (nylon or aluminum) and carburetor - Weber 40 or 45 DCOE

• Mounting flange for a Weber carburetor on an intake manifold or intake pipe that does not have O-rings or connecting elements.
• Provides a better seal and greater flexibility between the carburetor and the intake manifold. This isolates the carburetor from engine vibrations to prevent disturbing the settings.
• Spacer sold individually with two O-rings (two kits required per carburetor).

Spacer Specifications:

• Mounting Hole Spacing: 74mm
• Spacer Thickness: 5.50mm
• Inner Diameter: 40.80mm
• Outer Diameter: 64mm
• Mounting Hole Diameter: 8.3mm
• Material: Premium quality nylon

• Intake manifold mounting distance: 70mm and 110mm
• Carburetor mounting distance: 110mm and 70mm
• Flange thickness: 19.3mm
• Pipes diameter: Ø 40mm
• Flanges supplied with O-rings (x4), paper gaskets (x4), and mounting studs (x16)

These rigid aluminum flanges replace the original "flexible" rubber flanges, which tear with wear.

• Sold with water pump gasket
• Distance between two pulley mounting bolts (Center-to-center):50mm
• Pulley mounting using x4 M8 bolts (Not supplied)

The high-flow water pump increases performance Cooling without any modifications. It installs without any modifications, directly in place of the original Renault or Alpine pump.

Suitable for:

• R8 and R8G
• Caravelle and Floride S
• Alpine GT4
• A110 (1300cc engine)
• Matra Djet (1300cc engine)

• R8G / A110 (Engine 1255cc or1296cc ) Centering pins to be removed
• R5 Alpine (R1223)
• R5 Alpine Turbo (R122B)

Washer to be positioned on each side of the rubber bushing (Diablo rubber) on the anti-vibration spacer

Bushing specifications:

• • Washer inner diameter: Ø 8mm
  • Washer outer diameter: Ø 19mm
  • Height (Overall): 4mm
  • Sold individually
  • Two metal washers are required per rubber bushing (AVP48136)
