Diaphragm mechanism clutch kit - Ø 181mm / 20 splines / Fixing center distance 55mm

• Sold with 3 fixing screws and the oil seal (Ø 17x30x7mm)
• Guide to be mounted when replacing a clutch with a graphite thrust bearing with a modern diaphragm clutch
• It is necessary to drill and tap in the clutch bell to mount the adaptation guide.
• Mounting instructions supplied with the kit

• 4 spark plug wires + 1 coil wire
• 90° angled coil terminals
• Length of coil cable: 61cm
• Length of 2 spark plug wires: 26.5cm
• Length of 2 spark plug wires: 36.5cm
• We would like to point out that our spark plug wires are made with 7mm diameter red silicone wires and a standard copper core (wire material), which means they do not have interference protection.
• If the vehicle is equipped with electronic accessories If you have sensitive equipment, such as a radio, tripmaster, monitor, or certain electronic ignition kits, interference or disruption may occur.

Bearing Dimensions:

• Dimension: Original (Standard) Dimension
• Crankpin Diameter (A): Ø 43.98mm
• Housing Diameter (B): Ø 47.62mm
• Bearing Width (C): 17.75mm
• Bearing Thickness (D): 1.80mm
• Smooth, lug-type bearings with no grease holes or grooves
• Bearing Material: Bimetal

• Delivery in France only
• Thinner for use with paint reference: C021 - C022 - C023 - C015 - C016
