Water pump belt - 10x1125mm

Bearing Dimensions:

• Dimension: Stock dimension (Standard)
• Journal Diameter (A): Ø 46.00mm
• Housing Diameter (B): Ø 49.89mm
• Bearing Width (C): 24.50mm (x4)
• Bearing Width (C): 19.50mm (x6)
• Bearing Thickness (D): 1.92mm
• Smooth, lug-type bearings with grease holes (x5) and grooves (x5)
• Bearing material: Bi-metal

Inlet and outlet Ø 6-8mm

• Kit to be used with a coil of primary resistance between 2.5 and 3.5 ohms
• Compatible with coils AVP4708 and AVP4715
• Compatible for Ducellier igniter with an internal body diameter of Ø 58.8mm
• Not suitable for an igniter with externally adjusted breakers (different plate fixing points)
• 12V electronic ignition kit, with magnetic trigger which allows the elimination of the breakers and the capacitor
• Notice included
• Supplied with 3 screws for fixing the plate
• Instructions included

• Useful length (L on photo diagram number 3): 19.5mm
• Sold with the pin
• OE Renault / Alpine Ref: 0705322000
