Synchro of 3rd and 4th for ball locking - Box 365 - Ref 7700555558

• This ignition harness consists of 4 spark plug wires and one coil wire.
• Terminals on coil 90° angled
• Length of coil cable: 61cm
• Length of 2 spark plug wires: 26.5cm
• Length of 2 spark plug wires: 36.5cm
• We would like to point out that our spark plug harnesses are manufactured with 7mm diameter silicone wires, in black or red, with a standard copper core, which indicates that they do not have interference protection.
• If the car is equipped with sensitive electronic accessories, such as radios, Trip Master, Monitors, or certain electronic ignition kits, some interference or disruption may be observed.

Suitable for the following gearboxes:

• R12 / R12G / R17 / R17G : Gearbox 352 / 365-02 / 365-05 / 365-20
• A110 / A310.4 : Gearbox 365-02 / 365-05 / 365-20
• R4 / 4L : Gearbox 334-10 / 334-11

Synchro Characteristics:

• Outer cone with angle (A):9°
• All outer friction surfaces or sectors (x15) are identical and equidistant.
• Synchro smooth on the face opposite the synchro lug (See diagram)
• Renault OE Ref: 0428406300

Suitable for the following gearboxes:

• 330 Gearbox: 330-01 / ...
• 336 Gearbox : 336-...
• Gearbox 352: 352-10 / 352-11 / 352-13 / ...
• Gearbox 353: 353-03 / 353-13 / 353-33 / ...
• Gearbox 364: 364-05 / 364-06 / ...
• Gearbox 365: 365-...

We recommend carefully disassembling and identifying the synchros (9° or 6°40' angle, friction sector, etc.) in each gearbox, as we have observed some mixtures.

The gearbox numbers on the identification plate are not the most reliable way to identify the correct part.

Heater Hose Kit compatible with Alpine A310.4 (1st Version):

• A310.4 1600VE: From #1 to #1002
• A310.4 1600VF: From #1 to #21002

Inlet and outlet Ø 6-8mm

Segment Characteristics:

• • Segment Diameter:Ø 78mm
  • Thickness of Upper Segments (Fire-resistant): 1.75mm
  • Thickness of Intermediate Segments (Waterproof): 2mm
  • Low ring thickness (Scraper): 4mm

It is essential to check the ring end gap of each ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the instructions provided.or the values ​​given in the instruction manual.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120°.
