Sticker "Ferodo"

Note: There are two versions of the thermostat, distinguished by the diameter of the spring seat (small or large seat).

• Spring seat diameter: Ø 47.5 mm (Large seat)
• Thermostat outer diameter: Ø 69 mm
• Overall height: 55.5 mm
• Opening start temperature: 83°C
• Sold with gasket

• Useful length (L on photo diagram number 3): 19.5mm
• Sold with the pin
• OE Renault / Alpine Ref: 0705322000

For engine with water pump, x4 outlets.

Kit sold without valve stem seals (AVP1012), without copper base seals and without the timing case oil seal (AVP1029).

Self-locking washer:

• Inner diameter: Ø 2.5mm
• Outer diameter: Ø 8.5mm

• Useful length (L on photo diagram number 3): 17mm
• Sold with the pin
• OE Renault / Alpine Ref: 0705837200

Suitable for:

• R5 All models (1st Version)
• R12 / R15 / R16 / R17
• A110 V85 / A110.1600cm³ (SI / SX / SC)
• A310.4
• A310 V6 (Before 1981)

Gasket dimensions:

• Inner diameter: Ø 20mm
• Outer diameter: Ø 33mm
• Height (excluding lugs): 5mm
• Recessed diameter: Ø 26mm
• Push button diameter: Ø 19.5mm
