Right or left rear wheel cylinder - Ø19mm - 4CV ( From early 1951 to early 1953 )
- Filetage de la vis de fixation du bandjo: Ø 7/16"- 20UNF (Ø 11.11mm)
Sold individually
- Intake pipe : Ø 29mm
- Exhaust pipe : Ø 25mm
- Fixing : holes aligned
- Sold with water pump gasket
- Distance between two pulley mounting bolts (Center-to-center):50mm
- Pulley mounting using x4 M8 bolts (Not supplied)
Suitable for:
- R8 and R8G
- Caravelle and Floride S
- Alpine GT4
- A110 (1300cc engine)
- Matra Djet (1300cc engine)
The high-flow water pump increases performance Cooling without any modifications. It installs without any modifications, directly in place of the original Renault or Alpine pump.
The sets are supplied with the following components:
- Liners (x4)
- Pistons (x4)
- Rings (x12)
- Pin (x4)
- Circle clips (x8)
Dimensions of the different parts:
-
- Liner bore diameter: Ø 58mm
- Liner flange or top diameter (D): Ø 73mm
- Liner base diameter (A): Ø 62.50mm
- Overall height including skirts of the sleeves (C): 126mm
- Height from the top of the sleeve to the base gasket area (E): 112.80mm
- Shaft dimensions: Ø 14x50mm (Mounting with circlips)
- Segment thickness: 1.75mm / 2mm / 3.5mm (Fireproof/Sealing/Scraper)
- Base gasket type: Copper gasket
Caution:It is probable Modern cylinder liners and pistons are equipped with a shorter skirt. Installing modern cylinder liners and pistons to replace the original kits requires no modifications.
A shorter skirt promotes better lubrication and allows for an increased crankshaft stroke to prevent the skirt from contacting the connecting rod.
Piston installation direction: An arrow drawn perpendicular to the piston axis is marked on the top of the piston. It must be oriented in the direction of engine rotation during the connecting rod's downward stroke (see manufacturer's instructions or diagram). It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values given by the manufacturer or in the supplied instructions. During installation, the ring end gap must be evenly distributed around the piston circumference at 120° intervals.
&media=https://www.arnaudventouxpieces.com/5030-large_default/right-or-left-rear-wheel-cylinder-o19mm-4cv-from-early-1951-to-early-1953-.jpg){kind=link}
Clutch cable with chassis mounting
- Overall length:207cm
- Sheath length: 148cm
- Cable length: 196,5cm
Our cables are made in France and meet the assembly and quality standards of original equipment (OEM) cables from automotive manufacturers.
