Mechanical 3-tube fuel pump without priming lever (Type 821 and 841 engine) - R16 / R18 / Fuego

• Distance between two pulley mounting screws: 30mm
• Pulley is secured using 3 M7 screws (not supplied)
• The heater outlets can be plugged using two 16mm diameter rubber plugs and one 10mm diameter plug
• Water pump sold with water pump gasket, plate gasket, bleed plate, and bleed screw

Segment Characteristics:

• • Segment Diameter:Ø 70mm
  • Thickness of Upper Segments (Fire-resistant): 1.75mm
  • Thickness of Intermediate Segments (Waterproof): 2mm
  • Low ring thickness (Scraper): 3.5mm

It is essential to check the ring end gap of each ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the supplied instructions.or the values ​​provided in the instruction manual.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120°.

Bearing Dimensions:

• Dimension: Stock dimension (Standard)
• Journal Diameter (A): Ø 54.80mm
• Housing Diameter (B): Ø 58.75mm
• Bearing Width (C): 19.50mm
• Bearing Thickness (D): 1.95mm
• Smooth, lug-type bearings with grease holes (x10) and grooves (x5)
• Bearing Material: Bi-metal

Filter Dimensions:

• Inner Diameter (D2): Ø 260mm
• Outer Diameter (D1): Ø 210mm
• Height (H1): 61mm
• Height (H2): 57mm

The dimensions given are for guidance only; slight variations of a few millimeters are possible depending on availability.

Suitable for:

• Box 336
• Box 352
• Box 364-05 / 364-06
• Box 365-00 / 365-02 / 365-05
• Box 365-10 / 365-14 / 365-20 / 365-24 / 365-28 / 365-29
• Box 395
• Box 385 / NG5
