Fuel pump paper gasket - Ref 7700564395

Bleeder screw specifications:

• Thread diameter: M7 - 1.00 pitch
• Overall length: 26.3 mm
• Length under head: 15.5 mm
• Thread length: 10 mm
• Wrench size: 8
• Sold individually

Ideal for prepared engines or to replace a mechanical fuel pump.

• Flow rate: 125l/h
• Max pressure: 0.30bar
• Suction: -0.10bar
• 220° adjustable inlet and outlet tube: Ø 8mm
• Self-regulated fuel pump
• Dimensions: 73x126mm / Weight: 820g

Ideal for vehicles with the engine in the rear position with a tank at the front, pump to be positioned close to the tank.

It It is recommended to mount the pump horizontally, with the "Out" outlet at the top.

Pay attention to the connection polarity: red cable "+" / black cable "-"

• Kit to be used with a coil of primary resistance between 2.5 and 3.5 ohms
• Compatible with coils AVP4708 and AVP4715
• Compatible for Ducellier igniter with an internal body diameter of Ø 58.8mm
• Not suitable for an igniter with externally adjusted breakers (different plate fixing points)
• 12V electronic ignition kit, with magnetic trigger which allows the elimination of the breakers and the capacitor
• Notice included
• Supplied with 3 screws for fixing the plate
• Instructions included

With Needle 1.25

• Bleeder Screw Diameter: Tapered Thread - 1/8" NPTF (+/- 10.29mm)
• Original OE Ref: 6072180 / 0607218000 / 6072471 / 0607247100 / 7703075009

Please note this hose cannot replace the original oil hoses, use only to carry out an adaptable assembly using a connector and a new radiator.

Material: Black synthetic braid

Maximum operating pressure 35 bar and burst pressure 138 bar
