"Dauphine" chrome monogram

• Fuel pump with priming lever
• Inlet and outlet pipe diameter: Ø 6mm
• Supplied with a paper gasket
• Suitable for Ventoux, Billancourt, and Cléon engines.

Also suitable for:

• Dauphine with crankshaft pulley Ø 108mm

• Bleeder Screw Diameter: Tapered Thread - 1/8" NPTF (+/- 10.29mm)
• Original OE Ref: 6072180 / 0607218000 / 6072471 / 0607247100 / 7703075009

Bellows attached to the gearbox output and the control rod, designed to protect the control joint from dirt and road spray.

Bellows dimensions:

• Inlet diameter: Ø 26mm
• Outlet diameter: Ø 20mm
• Length at rest: 80mm
• Renault OE Ref.: 6055955 / 6031398

• Ball Ø 8mm / Stem M5
• Adjustment range between 65mm and 90mm

Segment Characteristics:

• Segment Diameter:Ø 58mm
• Thickness of Upper Segments (Fire-resistant): 2mm
• Thickness of Intermediate Segments (Waterproof): 2mm
• Lower piston ring thickness (scraper): 3.5mm

It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the supplied instructions.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120°.

Suitable for vehicles:

• 4CV / Juvaquatre: Type 662 Engine (From June 1956)
• Dauphine / Dauphinoise / Estafette / Floride A106 / A108: Type 670 Engine
• R4: Billancourt Type 800-02/05 Engine (From 1962)

Bearing Dimensions:

• Dimensions: Original (Standard) Dimensions
• Crankpin Diameter (A): Ø 38.00mm
• Housing Diameter (B): Ø 41.14mm
• Bearing Width (C): 21.18mm
• Bearing Thickness (D): 1.57mm
• Smooth, lug-type bearings with no grease holes or grooves
• Bearing Material: Bimetal
