Bronze valve guide with shoulder - Ø 6mm - 4CV (1st model)

• Outer diameter: Ø 22mm
• Wire diameter: Ø 2.5mm
• Free length: 38mm
• Total number of turns: 8

Sold individually

Joint to be adjusted to the length and joint to be glued either

Bearing Dimensions:

• Dimension: Repair Dimension (+0.25)
• Junnel Diameter (A): Ø 39.75mm
• Housing Diameter (B): Ø 44.01mm
• Bearing Width (C): 27.13mm (x2)
• Bearing Width (C): 30.12mm (x2)
• Bearing Width (C): 32.87mm (x2)
• Bearing Thickness (D) : 2.11 mm
• Smooth, lug-type bearings with grease holes (x4) and grooves (x6)
• Bearing material: Bi-metal

• The kit contains the following studs: M6x25 x3pcs (Ref 1016060256) + M6x30 x2pcs (Ref 1016060306) + M6x45 x1pcs (Ref 7059146)
• Only for water pumps with 7 mounting holes
