Water pump - R4 / R5A (1223) and R5AT (122B)

• This ignition harness consists of4 spark plug wires and 1 coil wire.
• We would like to point out that our spark plug wires are made with Ø 7 mm silicone wires, black in color, with a standard copper core (wire material), which indicates that they do not have interference protection.
• If the vehicle is equipped with sensitive electronic accessories, such as Radios, tripmasters, monitors, or certain electronic ignition kits may cause interference or disruption.

• OE Renault Ref: 7703090187 / 0857568100 / 7703090277

• To wrap around an R4/4L, six meters of reed are needed, with about 30 cm of margin.

Suitable for:

• R5 Alpine (R1223)
• R5 Alpine Turbo (R122B)

Silentbloc Dimensions:

• Inner Diameter (D1): Ø 37.1mm
• Outer Diameter (D2): Ø 55.2mm
• Height (H1): 27mm
• Height (H2): 59mm
• Silentbloc Rubber Hardness: 60 Shore

• Gear knob covered in high-quality imitation leather
• Resin pad with 5-speed gear selector and reverse gear (identical to the original)
• Gear knob to stick on the gear lever
• OE Renault Ref: 6001013385

Suitable for:

• • Estafette: Cléon 1108cc engine
  • R4 F6/GTL (Engine 688, C1E): Cléon 1108cc engine
  • R5 TL/GTL and Commercial Vehicles: Cléon 1108cc engine
  • R6 TL: Cléon 1108cc engine
  • R8 Major (R1132) / R8S (R1136): Cléon 1108cc engine
  • R10: Cléon engine 1108 cm³

The sets are supplied with the following components:

• Liners (x4)
• Pistons (x4)
• Rings (x12)
• Pin pins (x4)

Dimensions of the various parts:

• Liner bore diameter: Ø 70 mm
• Flange or top diameter (D): Ø 85.80 mm
• Liner base diameter (A):Ø 75.44mm
• Overall height including skirts of cylinder liners (C): 135mm
• Height from top of cylinder liner to base seal area (E): 94.85mm
• Panel dimensions: Ø 18x62mm (Cirlip-free mounting)
• Ring thickness: 2mm / 2mm / 3.5mm (Fireproof/Sealing/Scraper)
• Base seal type: Paper gasket

Piston mounting direction: one arrow drawn perpendicular to the axis of the piston, figure on the top of the piston. It must be oriented in the direction of engine rotation during the connecting rod's downward stroke (see manufacturer's instructions or diagram).

It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the supplied instructions.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120° intervals.
