Thermal contact on cylinder head - 97°C

This brake limiter replaces the original non-adjustable rear brake proportioning valve.

The limiter is not load-dependent (it does not vary according to the vehicle's load).

Its adjustment is manual, using the calibration screw. Adjustment can be made either statically, using brake pressure gauges and referring to the manufacturer's data, or dynamically (see description below).

Limiter specifications:

• Inlet thread (x1): 3/8-24UNF (Male cone)
• Outlet thread (x2): 3/8-24UNF (Male Taper)
• Mounting Screw Hole Diameter: Ø 8.5mm
• Limiter Adjustment Range: 5 turns
• Limiter delivered unadjusted (screw loosened): Rear brake pressure limited to maximum

• Air intake trumpet/trumpet filters for WEBER 45DCOE carburetor
• Mesh filters made of two layers of stainless steel mesh, with an intermediate filter layer ensuring optimal engine protection
• Easily washable and removable
• Suitable for trumpets with an outer flange diameter between Ø 60mm and 70mm
• Filter inner diameter: Ø 58mm
• Filter outer diameter: Ø 80mm
• The filter length when installed on a 63mm trumpet is 82mm (overall)
• Can be mounted on the entire assembly cones from the AVP catalog

Nut specifications:

• Thread diameter: M8x1.25
• Width (overall): 15.50 mm
• Material: Brass
• 13 mm wrench
