Steel ring in rear wheel shaft boot - Simca all models - Ref 23176R

• Kit to be used with a coil of primary resistance between 2.5 and 3.5 ohms
• Compatible with coils AVP4708 and AVP4715
• Compatible for Ducellier igniter with an inner body diameter of Ø 58.8mm
• Not suitable for an igniter with externally adjusted breakers (different plate fixing points)
• 12V electronic ignition kit , with magnetic trigger which allows the elimination of the breakers and the capacitor
• Notice included
• Supplied with 3 screws for fixing the plate
• Instructions included

Fan trigger temperature 82°C

Fan stop temperature 72°C

The central unit is connected as follows:

• The 12V power supply (+ battery) wire on the "X" or "+" terminal
• The Switch or stalk control wire on the "L" or "Z" terminal
• The repeater indicator light wire (LED) on the "P" terminal

• This ignition harness consists of 4 spark plug wires and 1 coil wire, each 7mm in diameter.
• It does not have interference suppression.

If the vehicle is equipped with sensitive electronic accessories, such as a radio, trip meter, monitor, or certain electronic ignition kits, interference or disruptions may occur.

• Coil wire length: 450mm
• Spark plug wire lengths: 350mm / 350mm / 350mm / 350mm

Ignition cables with copper core with interference suppression,

Copper is an excellent conductor However, it is very susceptible to corrosion. Therefore, the copper core of this type of cable harness is coated with tin. This tin layer protects the copper from oxidation.

The copper core is also coated with silicone rubber for increased durability and electrical insulation. The outer silicone rubber insulation can withstand temperatures up to 220°C and is also resistant to oil and gasoline splashes. Cables with a copper core do not have internal interference suppression.
