Solex 22 ICBT carb gasket set

Dimensions:

- Length 145mm

- Interior Ø 46mm and Ø of the rod 10mm

Kit containing a paper gasket and a specific thermal spacer/gasket.

The thermal spacer insulates the carburetor from engine heat, thereby limiting vapor lock issues.

Gasket specifications:

• Mounting hole spacing: 44mm
• Mounting hole diameter: Ø 7mm
• Inner diameter: Ø 23mm
• Paper gasket thickness: 0.7mm
• Thermal spacer thickness: 1.3mm
• Material: Paper gasket / Thermal spacer
• Sold as a 2-piece kit

The sets are supplied with the following components:

• Liners (x4)
• Pistons (x4)
• Rings (x12)
• Pin (x4)
• Circle clips (x8)

Dimensions of the various parts:

• • Liner bore diameter: Ø 54.5mm
  • Liner flange or top diameter (D): Ø 72.77mm
  • Liner base diameter (A): Ø 60mm
  • Overall skirt height (C): 122mm
  • Height from top of cylinder liner to base gasket reach (E): 111.25mm
  • Shaft dimensions: Ø 14x46mm (Cirlip-free mounting)
  • Ring thickness: 2mm / 2mm / 3mm (Fireproof/Sealing/Scraper)
  • Base gasket type: Copper gasket

Caution:It is likely that the cylinder liners and pistons are manufactured Modern pistons are equipped with a shorter skirt. Installing modern cylinder liners and pistons, to replace the original kits, requires no modifications.

A shorter skirt promotes better lubrication and allows for an increased crankshaft stroke to prevent the skirt from contacting the connecting rod.

Piston installation direction: An arrow drawn perpendicular to the piston axis is marked on the top of the piston. It must be oriented in the direction of engine rotation during the connecting rod's downward stroke (see manufacturer's instructions or diagram). It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the supplied instructions. During installation, the ring end gap must be evenly distributed around the piston circumference at 120° intervals.

• • Angled hose outlet: Ø 3/8" - 24UNF (Ø 9.52mm)

Suitable for:

• • 4CV: Right Rear Brake (From early 1956 to the end)
  • Dauphine / Floride: Right Rear Brake
  • Alpine A106 / A108: Right Rear Brake

• Black polyurethane adhesive for rubber seals
• High adhesion, temperature resistant up to 90°
