Handbrake lever rubber bellows (Under chassis) - Ref 4276660

For 4-speed gearbox (Type 330)

• • Overall length: 191.5 cm
  • Sheath length 1: 80 cm
  • Sheath length 2: 82 cm
  • Cable length: 189 cm
  • Cable end diameter: Ø 11 mm
  • Cable supplied with square cable ends
  • Renault OE part number: 8558991 / 8557975

For Dauphine / Caravelle / R8 / R8G / Alpine A108 / Alpine GT4 / Alpine A110

Our cables are made in France and meet the assembly and quality standards of original equipment (OEM) cables from automotive manufacturers.

Dowel Dimensions:

• Dowel Thread: M12 ((125 Pitch / Class 10.9)
• Dowel Head Diameter: Ø 19.50mm
• Dowel Recess Diameter: Ø 14.30mm
• Dowel Length Under Head: 33mm
• Dowel Overall Length: 38mm

Suitable for:

• Alpine A110 1300 / 1600: (Front and rear hubs with disc brakes)
• Alpine GT4:(Front and rear hubs with disc brakes)
• Caravelle: (R1133) / Floride (R1131):(Front and rear hubs with disc brakes)
• Dauphine: R1094 and R1095(Front and rear hubs with disc brakes)
• Matradjet:(Front and rear hubs with disc brakes)
• R8 / R10: (Front hubs with disc brakes)
• R8 G: R1135 (Front and rear hubs with disc brake)
• R12: All models (Rear hub with drum brake)
• R12 G: R1173 (Front and rear hubs with disc brake)
• R16 TS: R1151 (Rear hub with drum brake)
• R16 L/TL: R1153 (Front hub with disc brake and rear hub with drum brake)
• R17 TL: R1312 From serial number 30471 to the end of series 30470 (Front hub with disc brake and rear hub with drum brake)
• R17 TL: R1322 From serial number 2451 to the end of series 30470 Series (Front hubs with disc brake and rear hubs with drum brake)
• R17 G:(Front and rear hubs with disc brake)

x1 pot of fine grain 240 lapping paste

x1 pot of coarse grain 120 lapping paste

Delivery in France only

• Does not absorb moisture, thus protecting brake systems from rust, which accumulates on wheel cylinders and destroys the brake pads after a few brake applications when the brakes are restarted in the spring.
• DOT 5 approved (not to be confused with DOT 5.1)

Directions for use:

• Before using this brake fluid, your system must be thoroughly bled, rinsed with rubbing alcohol, and dried.

Segment Characteristics:

• • Segment Diameter: Ø 70mm
  • Thickness of Upper Segments (Fire-resistant): 2mm
  • Thickness of Intermediate Segments (Waterproof): 2mm
  • Low ring thickness (Scraper): 3.5mm

It is essential to check the ring end gap of each ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the supplied instructions.or the values ​​provided in the instruction manual.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120°.

AVP recommends the reinforced gearbox side silentblocks Ref 4305, for reasons of reliability and ease of assembly.
