"Renault" crest

• R4 (Billancourt Engine): Alternator belt - Ref 0854249800
• R5 Alpine (1223) / R5 alpine Turbo (122B): Water pump belt

• Fixed by drum Ø 14mm on the wiper shafts
• Width of the arm at the point where it fits into the blade: 6mm

• Harness for mounting with the coil on the rear skirt
• Coil wire length: 53cm
• Ignition wire length: 53cm / 55cm / 60cm / 64.5cm
• This ignition harness consists of4 spark plug wires and 1coil wire.
• We would like to point out that our spark plug wires are made withØ7mm silicone wire,blackin color, with a standard copper core (wire material), which indicates that they do not have interference protection.
• If the car is equipped with sensitive electronic accessories, such as a radio, tripmaster, monitor, or certain electronic ignition kits, it may Some interference or disruption may occur.

• Box of cotter pins (450 pieces)

For mounting the oil pressure sender (AVP4079) on the R5 alpine engine

The central unit is connected as follows:

• The 12V power supply (+ battery) wire on the "X" or "+" terminal
• The Switch or stalk control wire on the "L" or "Z" terminal
• The repeater indicator light wire (LED) on the "P" terminal
