Platinum screw SEV junior (Type SEV 908105) - ref 8544108

The thermal spacer insulates the carburetor from engine heat, thereby limiting "vapor lock" issues.

Spacer specifications:

• Mounting hole spacing: 45mm
• Mounting hole diameter: Ø 6.2mm
• Inner diameter: Ø 23mm
• Thickness: 5mm
• Material: Bakelite
• Sold individually

Suitable for engines:

• Engine Type 662: 4CV / Juvaquatre / A106
• Engine Ventoux Type 670-1: Dauphine (Except R1093 and Gordini R1095) / Estafette / Floride (R1092) / A108

Valve sold individually

• Renault OE Ref: 7700502325 / 7700511457 / 7703087032 / 7703087087

• Special Premium Quality graphite for clutch release bearings
• Important: The release bearing clamping screw must be placed on the side opposite the fork
• It is possible to keep the release bearing and replace only the graphite ring if worn.
• Depending on the diameter of the return spring, it may be necessary to re-drill the release bearing mounting.
• It is recommended to soak the release bearing in warm engine oil and then wipe it dry before installation to avoid squeaking noises

• Fuel pump with priming lever
• Inlet and outlet pipe diameter: Ø 6mm
• Supplied with a paper gasket
• Suitable for Ventoux, Billancourt, and Cléon engines.
