Dual chrome "Devil" style exhaust silencer for original manifold - R8 / R8.S / Caravelle / A110 V85 (1st version)

For 4-speed gearbox (Type 330)

• • Overall length: 191.5 cm
  • Sheath length 1: 80 cm
  • Sheath length 2: 82 cm
  • Cable length: 189 cm
  • Cable end diameter: Ø 11 mm
  • Cable supplied with square cable ends
  • Renault OE part number: 8558991 / 8557975

For Dauphine / Caravelle / R8 / R8G / Alpine A108 / Alpine GT4 / Alpine A110

Our cables are made in France and meet the assembly and quality standards of original equipment (OEM) cables from automotive manufacturers.

Dimensions:

• Head: 12.5x11mm Rectangle
• Height under head: 15mm
• Overall height: 16.5mm

Suitable for:

• Exterior trim: Juvaquatre / R4 / R8 / Caravelle / R12 / R15 / R17 / Alpine A108
• Door panel: R4

OE Renault Ref: 0852640300 / 0854979000 / 7703076030 / 7703076031 / 7703076132

Caliper equipped with square joint.

Fit on:

• Dauphine (Disc brakes)
• R8 / Caravelle / Floride S
• A110 (Small brakes mounting)

Pulley specifications:

• Suitable for a 10mm wide belt
• Pulley outer diameter: Ø 140mm
• Crankshaft bore diameter: Ø 24mm
• Keyway dimensions: Width 5mm / Length 34mm
• Oil seal contact surface diameter: Ø 35mm
• Oil seal contact surface length: 20mm
• Central hub offset: 34.2mm
• Belt offset: from the center of the belt to the end of the pulley facing the timing cover: 31mm

A steel sleeve is fitted to the oil seal contact surface to improve sealing and reduce pulley wear.

• Renault OE Ref.: 7700507524 / 7700650823

• Identical to the YORKA and SEIMA branded caps
