Diaphragm mechanism - Ø215mm - 1600cc

REF: 7700519257

Without cylinder head gasket

• Distance between two pulley mounting screws: 30mm
• Pulley is secured using 3 M7 screws (not supplied)
• The heater outlets can be plugged using two 16mm diameter rubber plugs and one 10mm diameter plug
• Water pump sold with water pump gasket, plate gasket, bleed plate, and bleed screw

• OE Renault Ref: 0852775600 / 0852957000 / 7703090181

Flexor Specifications:

• • Mounting hole spacing:4 x 50.50 mm
  • Mounting hole diameter: Ø 8.4 mm
  • Center hole diameter:Ø 10.50 mm
  • Flexor thickness: 11 mm
  • Material:Rubber flexor with metal reinforcement
  • Supplied with 4 x M8 x 20 mm screws and 4 x nylock nuts

For some assemblies with a center screw, replacing this screw with a socket head cap screw (SHCS) or modifying the flexor may be necessary.
