Crankshaft pinion for timing (17 teeth) - Premium Quality

Bearing Dimensions:

• Dimension: Original (Standard) Dimension
• Crankpin Diameter (A): Ø 43.98mm
• Housing Diameter (B): Ø 47.62mm
• Bearing Width (C): 20.75mm
• Bearing Thickness (D): 1.81mm
• Smooth, lug-type bearings with no grease holes or grooves
• Bearing Material: Bimetal

The position of the groove for securing the half-moons must be checked.

There are two mounting types for intake valves (see diagram): a square groove (BK type) and a round groove (KK type).

• Valve angle: 45°
• Keeper type (Collet): KK (x1 Round groove)
• Renault / Alpine OE Ref: 7700509771 / 7700561319 / 7701458180 / 7701458186

Suitable for:

• R4: 852cc and 1108cc engines (Cléon engine)
• Rodéo
• R5 (GTL / GTS / TL): 1108cc engine
• R8 and R8 Major (3rd mounting type): 688-02 / 688-06 / 688-09 engines
• Estafette: 1289cc engine (Type 810)
• R12 (L / TL / TS) and R15 (TL and GTL): 1289cc engine (Type 810)
• Super 5: C1E and C1C engines
• Clio 1: C1G and C3G engines
• Twingo: C3G engine
• Alpine GT4: 1289cc engine (Type 810)
• Alpine A110 V85 : 1289cm³ engine (Type 810)

• Crimp Diameter: Ø 70.9mm
• Thickness: 1.45mm (Original dimension)
• Material: Multi-layer with steel crimp

• This ignition harness consists of4 spark plug wires and1 coil wire.
• We would like to point out that our spark plug wires are made with 7 mm diameter silicone wires, black in color, with a standard copper core (wire material), which means they do not have interference protection.
• If the vehicle is equipped with sensitive electronic accessories, such as a radio, tripmaster, monitor, or certain kits electronic ignition, interference or disruption may occur.
