Clutch cable - R12G / R15 / R17 - Ref 7701454201 / 7700550773

• 4 spark plug wires + 1 coil wire
• 90° angled coil terminals
• Length of coil cable: 61cm
• Length of 2 spark plug wires: 26.5cm
• Length of 2 spark plug wires: 36.5cm
• We would like to point out that our spark plug wires are made with 7mm diameter red silicone wires and a standard copper core (wire material), which means they do not have interference protection.
• If the vehicle is equipped with electronic accessories If you have sensitive equipment, such as a radio, tripmaster, monitor, or certain electronic ignition kits, interference or disruption may occur.

• Material: mixed fibers, acrylic and wool
• Thickness: 6mm
• Width: 1 meter
• Sold by the linear meter

Suitable for:

• A110.1600 SC / SI (VD) / SX (VH) / A310.4 : Upper and lower rear wishbone
• R12.G : Lower front wishbone, central rear wishbone

• For piston kit liners Ø 79mm (AVP6085) and Ø 77.8mm (AVP60134)

• The sets are supplied with the following components:

  • Liners (x4)
  • Pistons (x4)
  • Segments (x12)
  • Axles (x4)

  Dimensions of the individual parts:

  • Liner bore diameter: Ø 79mm
  • Liner collar or top diameter (D): Ø 96mm
  • Liner base diameter (A): Ø 84mm
  • Height including skirts (Overall) of the sleeves (C): 143.50 mm
  • Height from the top of the sleeve to the base seal area (E): 92.60 mm
  • Shaft dimensions: Ø 21 x 69 mm
  • (Cirlip-free mounting) Segment thickness: 1.75 mm / 2 mm / 4 mm (Fireproof/Sealing/Scraper)
  • Base seal type: O-ring

Piston mounting direction: an arrow drawn perpendicular to the piston axis is shown on the top of the piston. It must be oriented in the direction of engine rotation during the connecting rod's downward stroke (see manufacturer's instructions or diagram).

It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values ​​given by the manufacturer or in the supplied instructions.

During installation, the ring end gap must be evenly distributed around the piston circumference at 120°.
