Carburetion main jet - Solex Ø 100

Installation orientation: The end with the two closest-spaced holes is installed on the inspection plate side (opposite the water pump).

Tube orientation: The holes must be aimed towards the valve seats at a 30° angle from the vertical.

• Tube outer diameter: Ø 14mm
• Tube length (overall): 325mm
• Material: Stainless steel
• Renault OE Ref.: 5522581 / 0555258100 / 0555465300

• Fixed by drum Ø 14mm on the wiper shafts
• Width of the arm at the point where it fits into the blade: 6mm

Kit containing 2 paper gaskets and one specialized thermal gasket.

The thermal gasket insulates the carburetor from engine heat, thereby limiting vapor lock issues.

Gasket specifications:

• Mounting hole spacing: 53mm
• Mounting hole diameter: Ø 8.4mm
• Inner diameter: Ø 28mm
• Paper gasket thickness: 0.25mm
• Thermal gasket thickness: 1.3mm
• Material: paper gasket / thermal gasket
• Sold as a 3-gasket kit

Inlet and outlet Ø 6-8mm

Suitable for:

• 4CV/Juvaquatre
• Dauphine (1st model)
• Alpine A106

• Fuel pump with priming lever
• Inlet and outlet pipe diameter: Ø 6mm
• Supplied with a paper gasket
• Suitable for Ventoux, Billancourt, and Cléon engines.

• Capacitor capacity 0.27µF
