Hub Specifications:

• Outer Diameter: Ø 180mm
• Wheel Stud Bolt Hole Spacing: 3x130mm
• Wheel Stud Hole Diameter: Ø 13.4mm
• Wheel Stud Bolt Hole Spacing: 3x130mm
• Original type hub with 10 splines
• Hub sold without wheel studs
• Renault OE Reference: 0428666800

Hub Specifications:

• Outer Diameter: Ø 180mm
• Inner Bearing Race Diameter: Ø 47mm
• Wheel Stud Hole Diameters: Ø 13.5mm
• Wheel Stud Bolt Hole Spacing: 3x130mm
• Brake Disc Bolt Hole Diameters: Ø 10mm
• Brake Disc Bolt Hole Spacing: 3x71mm
• Center Cap Bolt Diameter: Ø 42mm
• Hub sold without bearing and without stud
• Renault OE ref: 0833144700 / 0833096600 / 7701455396

Brake Disc Specifications:

• Outer Diameter: Ø 228mm
• Inner Centering Diameter: Ø 83mm
• Mounting Hole Spacing: 49.5mm
• Mounting with 6 Bolts: M8x125
• Disc Offset: 28.5mm
• Brake Disc Thickness: 10mm (Solid Discs)
• Sold in pairs (2 discs)

Important Brake discs have a specific mounting direction that must be respected; they are interchangeable.

Mounting direction of a solid, non-ventilated brake disc : Discs must be installed so that the edge of the grooves closest to the outer edge of the disc makes contact with the brake pad first.

For competition use only; do not use these discs on public roads.

Suitable for:

• R4 Saloon / Van F4 and F6 / Rodeo : Front disc
• R5 Alpine (1223): Disc front
• R5 Alpine Turbo (122B) / Alpine Coupe / GR2: Rear disc
• R12 / R15TL: Front disc
• R12G / R17G / R17TS: Rear disc

Brake Disc Specifications:

• Outer Diameter: Ø 260mm
• Inner Centering Diameter: Ø 60mm
• Mounting Hole Spacing: 71mm
• Disc Offset: 33.5mm
• Brake Disc Thickness: 7.5mm (Solid Disc)
• Sold in pairs (2 discs)

Important: Brake discs have a specific mounting direction that must be observed. Interchangeable.

Installation direction of a solid, non-ventilated brake disc: The discs must be installed so that the edge of the grooves closest to the outer edge of the disc makes contact with the brake pad first.

For competition use only; do not use these discs on public roads.

• Steering wheel covered in aged black leather for an authentic, vintage look with white stitching and parallel patterns
• Steering wheel entirely handmade
• Steering wheel outer diameter: Ø 350mm
• Thickness: 39mm
• Steering wheel cross-section: 30mm
• Mounting hole spacing on the hub: 6x70mm
• Supplied with a "Momo Vintage" center cap with horn

• • Steering wheel covered in high-quality black leather, white stitching with parallel patterns
  • Steering wheel entirely handmade
  • Steering wheel outer diameter: Ø 320mm
  • Thickness: 0mm (Flat steering wheel)
  • Steering wheel cross-section: 30mm
  • Mounting hole spacing on the hub: 6x70mm
  • Supplied with "Momo" center cap with horn

• • Steering wheel covered in high-quality black leather, white stitching with parallel patterns
  • Steering wheel entirely handmade
  • Steering wheel outer diameter: Ø 320mm
  • Thickness: 0mm (Flat steering wheel)
  • Steering wheel cross-section: 30mm
  • Mounting hole spacing on the hub: 6x70mm
  • Supplied with "Momo" center cap with horn

• New generation of Ultra-compact H4 LED bulb with dimensions similar to a standard halogen bulb
• Bulb without ventilation and without ballast, made with specific materials to limit bulb heat
• Ideal for improving vehicle visibility while maintaining a retro look (Yellow color)
• Very high-quality bulb, quick and easy installation - Made in Japan

Bulb specifications:

• Models: H4 (Low Beam / High Beam)
• Base type: P43t
• Technology: LED
• Voltage: 12V
• Consumption: 23W
• Lumens: 3800ml / 3000ml
• Retro Look Color: 2500K - Yellow (Ideal for a Retro look)
• Bulb Sold in pairs

• • New generation of ultra-compact H4 LED bulbs with dimensions similar to a standard halogen bulb
  • Bulb without ventilation or ballast, made with specific materials to limit bulb heat generation
  • Ideal for improving vehicle visibility while maintaining a retro look (White color)
  • High-quality bulb, quick and easy installation - Made in Japan

Bulb Specifications:

• • • Models: H4 (Low Beam/High Beam)
    • Base Type: P43t
    • Technology: LED
    • Voltage:12V
    • Consumption: 23W
    • Lumens: 3800ml / 300ml
    • Retro Look Color: 4000K - White (Ideal for a Retro look)
    • Bulb Sold in pairs
