Rear cover push button - R8 / A110

Self-locking washer:

• Inner diameter: Ø 2.5mm
• Outer diameter: Ø 8.5mm

• Réf OE Alpine : 6000001066 + 6000001067 + 6000001068 + 6000001069 + 6000000474

Fitting dimensions:

• Master cylinder side (Male thread): M16x150
• Copper pipe fitting side (Female thread): Ø 1/2"-20 UNF (Ø 12.70mm)

To turn on a temperature warning light

Trigger temperature 115°C

The central unit is connected as follows:

• The 12V power supply (+ battery) wire on the "X" or "+" terminal
• The Switch or stalk control wire on the "L" or "Z" terminal
• The repeater indicator light wire (LED) on the "P" terminal
