"GOTTI red" self-adhesive sticker for Ø 64.5mm plastic cover

This brass pinion replaces the original plastic pinion.

Pinion Dimensions:

• • Outer Diameter: Ø 52.50mm
  • Thickness: 6.25mm

Suitable for:

• • R12 / R12G / R15
  • R17 / R17G
  • Alpine A310.4
  • Alpine A310 V6 (All models)

• 4 spark plug wires + 1 coil wire
• Terminals on coil straight
• Length of coil cable: 61cm
• Length of 2 spark plug cables: 26.5cm
• Length of 2 spark plug cables: 36.5cm
• We would like to point out that our spark plug wires are made with 7mm diameter, black silicone wires with a standard copper core (wire material), which means they do not have interference protection.
• If the vehicle is equipped with sensitive electronic accessories, such as a radio, tripmaster, monitor, or certain electronic ignition kits, interference or disruption may occur. happen.

Kit specifications (Tie rods / Ball joints and boots):

• Ball joint taper diameter (Steering knuckle side): Top of taper Ø 11mm / Bottom of taper Ø 12mm
• Ball joint taper stud thread diameter: M10 x 1.25 (right-hand thread)
• Ball joint stud thread diameter (into tie rod): M14 x 1.50 (right-hand thread)
• Tie rod thread diameter (into steering rack): M12 x 1.00 (right-hand thread)
• Minimum length of tie rod/ball joint assembly: 26 cm (measured from the contact point against the steering rack to the center of the ball joint stud on the steering knuckle side)
• Maximum adjustment of the tie rod/ball joint assembly: 29 cm (measured from the contact point against the steering rack to the center of the ball joint at the steering knuckle end)
• Includes: 2 steering rack boots, 2 steering ball joints (with nuts and locknuts), and 2 steering tie rods.

Suitable for:

• R8 (All models)
• Caravelle / Floride S
• A110 (All models) / Alpine GT4
• Matradjet

This adjustable steering kit replaces the original "fork-type" steering tie rods.

To install the adjustable tie rods, you must remove the steering rack eyelet bushing and replace the steering rack boots with the specific AVP4620 boots (included in the kit).

• Supplied with self-adhesive thermal protection to be applied to the most suitable side depending on the installation.
• OE Renault Ref: 6000048783 / 6001005622

• Suitable for GOTTI rims or hubs
• Fits a 60mm mounting diameter on the rim side
• Cap outer diameter: Ø 64.5 mm

• Suitable for GOTTI rims or hubs
• Fits a 60mm rim-side mounting diameter
• Cap outer diameter: Ø 64.5 mm
• Diameter of the adhesive emblem recess: Ø 45mm
