Diamond Dimensions:
- Height: 34 mm
- Width: 22 mm
- One mounting stud: Ø 4 mm
In stock
Insulating strip for exhaust manifold - 50mm x 4.5m
Reference:
40129
€26.00
(tax incl.)
Customers who bought this product also bought:
- Cap thread:Tapered thread - BSP 3/8x16 (+/- 16.66mm / 1.33 pitch)
- Square head cap that can be tightened or loosened with a 10mm wrench.
- Renault OE part number:0702980300 / 7703075012
In stock
The kits are supplied with the following components:
- Cylinder Heads (x4)
- Domed Pistons (x4)
- Rings (x12)
- Pin (x4)
- Circle Clips (x8)
Dimensions of the various parts:
-
- Cylinder Head Bore Diameter: Ø 75.7mm
- Cylinder Head Flange or Top Diameter (D): Ø 89.75mm
- Cylinder Head Base Diameter (A): Ø 80mm
- Overall height including skirts of cylinder liners (C): 128mm
- Height from top of cylinder liner to base seal area (E): 94.80mm
- Shaft dimensions: Ø 20x63.5mm (Cirlip-free mounting)
- Ring thickness: 1.75mm / 2mm / 4mm (Fireproof/Sealing/Scraper)
- Base seal type: Paper gasket
Piston mounting direction: (arrow) drawn perpendicular to the axis of the piston, figure on the top of the piston. It must be oriented in the direction of engine rotation during the connecting rod's downward stroke (see manufacturer's instructions or diagram).
It is essential to check the ring end gap of each piston ring before installing them on the pistons, according to the values given by the manufacturer or in the supplied instructions.
During installation, the ring end gap must be evenly distributed around the piston circumference at 120° intervals.
Out of stock
- Suitable for older generation WEBER 40DCOE carburetors (the bearing surfaces differ from the shafts of modern versions)
- Caution: Mounting must be done with flat-head screws (AVP48052)
- Drilling required for accelerator pump control
- Overall shaft length: 180mm
- Part number 85 on the exploded view
In stock
- To wrap around an R4/4L, six meters of reed are needed, with about 30 cm of margin.
Out of stock
In stock
- For gearbox control shaft Ø 13mm
- Suitable for gearboxes: 330-A4 / 353 / 364-05 / 364-06
- OE Renault Ref: 98079333 / 0980793300 / 7701455390 / 7701501597
In stock
