Diamond for plastic grille
- This ignition harness consists of 4 spark plug wires and 1 coil wire, each 7mm in diameter.
- It does not have interference suppression.
If the vehicle is equipped with sensitive electronic accessories, such as a radio, trip meter, monitor, or certain electronic ignition kits, interference or disruptions may occur.
- Coil wire length: 550mm
- Spark plug wire lengths: 300mm / 300mm / 350mm / 350mm
This type of harness includes a fiberglass core supporting a conductive and magnetic silicone sheath around it around which a stainless steel wire is wound.
This winding works on the principle of a coil; an induced voltage is created by the electromagnetic flux generated by the passage of high voltage through the core of the cable.
The magnetic field fluctuates within the cable, while the stainless steel wire wound around it like a coil absorbs or compensates for the energy generated by the cable. Ignition leads equipped with an inductive resistor are wrapped with two layers of silicone and a layer of fiberglass. The internal silicone insulation ensures durability and protects against high voltages.
The fiberglass fabric increases the mechanical strength of the cable. The exterior silicone rubber insulation withstands temperatures up to 220°C and is resistant to hydrocarbons.
For original rim with fin "Turbine" and rim "Bobine"
- Suspension ball joints: M12x125 axle - Cone Ø 12.50mm to Ø 14mm
- Mounting center distance on the wishbone: 42mm and 51mm
Renault OE Ref: 7701450635 / 7701461161
- Hose thread: 3/8"x24UNF (outgoing cone)
- Fixing distance: 31.75mm
- Suspension ball joints: M12x125 axle - Cone Ø 12.50mm to Ø 14mm
- Mounting center distance on the wishbone: 42mm and 51mm
OE Renault Ref: 7701450637 / 7701461162
- Automatic spring-loaded tensioner
- Features a grease fitting to ensure lubrication and maintain tension of the chain guide against the chain
We prioritize quality and reliability: tensioner meets original equipment quality standards.
