Carburetor hose - R12.TS / A110.V85

Pulley specifications:

• Suitable for a 10mm wide belt
• Pulley outer diameter: Ø 140mm
• Crankshaft bore diameter: Ø 24mm
• Keyway dimensions: Width 5mm / Length 34mm
• Oil seal contact surface diameter: Ø 35mm
• Oil seal contact surface length: 20mm
• Central hub offset: 34.2mm
• Belt offset: from the center of the belt to the end of the pulley facing the timing cover: 31mm

A steel sleeve is fitted to the oil seal contact surface to improve sealing and reduce pulley wear.

• Renault OE Ref.: 7700507524 / 7700650823

• Hose inner diameter: Ø 17mm
• R4 (Billancourt Engine): R1120 / R1121 / R1122 / R1123 (From 01/1962)
• OE Renault Ref: 0852841500 / 0857576900 / 7705026840

• Fuel pressure gauge kit.
• Allows fuel pressure adjustment with the "King" filter REF 6825.
• Graduation from 0.20g up to 1 bar.
• With connector and clamp for 6 or 8 diameter flexible hoses.
• The pressure gauge can be removed after adjustment and the cap provided in the kit can be screwed on for greater privacy in the engine compartment.

Length: 60mm

Possibility of adaptation on other engines without oil filter

• R12 all models (except R12 Gordini)

• Black faux leather gear shift cover for Renault Alpine A110
• Black faux leather sewn onto 12mm thick foam
• Recommended installation with BOSTIK glue Ref,,,,,,,,,,,,,,,,,
