Rivet for plastic side strips

Dimensions:

• d: 2.4 mm
• L: 7.6 mm
• dk: 5 mm
• k: 0.9 mm
• from: 3 mm
• f:2.6mm
• w: 1.45 mm
• EA: 1 → 3 mm
• D1: 2.5 mm

Suitable for the following vehicles:

• R4 / 4L GTL
• R4 / 4L CLAN
• R9 / R11
• R25

M6x100 body screws

Dimensions:

• s: 10 mm
• k: 4 mm
• d2: 18 mm
• L: 20 mm
• d: M6 x 100

Suitable for the following vehicles:

• R4 / 4L
• R5
• R12

Pinch nut clip - Ø M6-100

Dimensions:

• L: 23.5 mm
• B: 15 mm
• X: 11.7 mm
• s: 0.8 mm
• d:M6 x 100
• F1: 0.5 → 4 mm

Dimensions:

• • dk: 17 mm
  • h: 11 mm
  • d: M6 x 1.00
  • B: 4.6 mm
  • A: 14.7 mm
  • D1: 10.4 mm
  • F1: 0.5 → 3.7 mm

Suitable for the following vehicles:

• • R8: Insert in the rear frame rails for securing the underbody panel
  • R19

Dimensions:

• L: 12.1 mm
• b1: 12 mm
• h: 8.5 mm
• d: M4 x 0.70
• B: 8.1 mm
• A: 12.1 mm
• F1: 1.2 → 1.6 mm

Suitable for the following vehicles:

• R12: For under-engine housing

Dimensions:

• L: 12.1 mm
• b1: 12 mm
• h: 8.5 mm
• d: M5 x 0.80
• B:8.1mm
• A: 12.1 mm
• F1: 1.2 → 1.6 mm

Dimensions:

• L: 12.1 mm
• b1: 12 mm
• h:8.5 mm
• d: M6 x 100
• B: 8.1 mm
• A: 12.1 mm
• F1: 1.2 → 1.6 mm

Suitable for the following vehicles:

• R8: For underbody sheet metal:08524978
• R16: Front Wings

Ref. OE: 7700520239

Dimensions:

• L: 19.5 mm
• b1: 12.8 mm
• h: 7.7 mm
• d: M6 x 100
• B: 8 mm
• A: 13 mm
• F1: 0.4 → 0.7 mm

Suitable for the following vehicle:

• R12

OE ref: 770044008 / 7703044171

Dimensions:

• dk:16.5mm
• h: 9.4 mm
• d:M5 x 0.80
• B: 4.6 mm
• A: 13.7 mm
• D1: 9.4 mm
• F1: 0.7 → 1.8 mm

Suitable for the following vehicle:

• R12: Insert into the dashboard

Lyre clip / fastener

Dimensions:

• l: 12mm
• L: 20mm

Fixing by screw or rivet
