• This aluminum flange is an evolution of nylon flanges, designed to improve reliability and prevent certain deformations related to use and high temperatures.
• Mounting flange for a Weber carburetor on an intake manifold or intake pipe that does not have O-rings or connecting elements.
• Provides a better seal and greater flexibility between the carburetor and the intake manifold. This isolates the carburetor from engine vibrations to prevent disturbing the settings.
• Spacer sold separately with two O-rings (Two kits required per carburetor)

Spacer Specifications:

• Mounting Hole Spacing: 72mm
• Spacer Thickness: 6mm
• Inner Diameter: Ø 45mm
• Outer Diameter: Ø 66mm
• Mounting Hole Diameter: Ø 8.5mm
• Material: Aluminum

• This aluminum flange is an evolution of nylon flanges, designed to improve reliability and prevent certain deformations related to use and high temperatures.
• Mounting flange for a Weber carburetor on an intake manifold or intake pipe that does not have O-rings or a connecting element.
• Provides a better seal and greater flexibility between the carburetor and the intake manifold. This isolates the carburetor from engine vibrations to prevent disturbing the settings.
• Spacer sold separately with two O-rings (Two kits required per carburetor)

Spacer Specifications:

• • Mounting Hole Spacing: 72mm
  • Spacer Thickness: 6mm
  • Inner Diameter: Ø 40mm
  • Outer Diameter: Ø 66mm
  • Mounting Hole Diameter: Ø 8.5mm
  • Material: Aluminum

• Mounting flange for a Weber carburetor on an intake manifold or intake pipe that does not have O-rings or connecting elements.
• Provides a better seal and greater flexibility between the carburetor and the intake manifold. This isolates the carburetor from engine vibrations to prevent disturbing the settings
• Spacer sold separately with two O-rings (Two kits required per carburetor)

Spacer Specifications:

• • Mounting Hole Spacing: 74mm
  • Spacer Thickness: 5.50mm
  • Inner Diameter: Ø 45.80mm
  • Outer Diameter: Ø 64mm
  • Mounting Hole Diameter: Ø 8.3mm
  • Material: High-Quality Nylon

• Mounting flange for a Weber carburetor on an intake manifold or intake pipe that does not have O-rings or connecting elements.
• Provides a better seal and greater flexibility between the carburetor and the intake manifold. This isolates the carburetor from engine vibrations to prevent disturbing the settings.
• Spacer sold individually with two O-rings (two kits required per carburetor).

Spacer Specifications:

• Mounting Hole Spacing: 74mm
• Spacer Thickness: 5.50mm
• Inner Diameter: 40.80mm
• Outer Diameter: 64mm
• Mounting Hole Diameter: 8.3mm
• Material: Premium quality nylon

• Suitable for WEBER 40 and 45 DCOE new generation carburetors Type 151 and 152 (the bearing surfaces are different from the shafts of older versions)
• Caution: The throttle plates or flaps must be mounted using flat-head screws. (AVP48052)
• The drilling of the mounting hole for the return pump control must be done manually, depending on the type of pump control.
• Overall shaft length: 180mm
• Thread diameter at the shaft ends: M7
• Number 85 on the exploded view

• Suitable for WEBER 40 DCOE carburetor
• Tune extends from the carburetor: 15mm
• Carburetor mounting via stud and nut
• Mounting hole spacing: 66mm
• Allows the installation of high-performance filters (AVP48099 or AVP48100) and sock filters (AVP48103)
• Ideal for competition use

For installation with new generation venturis (Ref. AVP48084 or AVP48085), the spacer (AVP48087) is recommended

to fill the space between the auxiliary venturi and the carburetor body.

Ideal velocity stack for mounting an R5 Alpine engine with two Weber 40 DCOE carburetors in an Alpine A110 with a large chassis

Radiator Dimensions:

• Inlet and Outlet Diameter: Ø 18.3mm
• Radiator Height: 185mm
• Radiator Width: 140mm
• Radiator Depth: 645mm
• Material: Aluminum + Satin Black Paint
• Original Renault OE Reference: 8550945 / 0855094500

Suitable for:

• R8 / R8G / R8S: All models
• Alpine A110: All models

Radiator Dimensions:

• Inlet and Outlet Diameter: Ø 18mm
• Radiator Height: 165.50mm
• Radiator Width: 132.50mm
• Radiator Depth: 65.50mm
• Material: Aluminum + Satin Black Paint
• Original Renault OE Reference: 8541555 / 0854155500

• Overall Length of Faucet: 93mm
• Length of Control Shaft: 39mm
• Mounting Screw Center-to-Center Distance: 30.5mm
• Diameter of Control Shaft: Ø 8mm
• Diameter of Mounting Holes: Ø 5.5mm
• Brass Faucet

• Overall Length of Faucet: 129mm
• Length of Control Shaft: 74mm
• Mounting Screw Center-to-Center Distance: 30.5mm
• Diameter of Control Shaft: Ø 8mm
• Diameter of Mounting Holes: Ø 5.5mm
• Brass Faucet
